3V 6V 12V Custom 370 DC Vibrating Motor Sector shaped Micro miniature Vibration Motor

3V 6V 12V Custom 370 DC Vibrating Motor Sector shaped Micro Miniature Vibration Motor

The 370 DC Vibration Motor is a high-performance vibrating motor designed for applications requiring high torque and strong vibrations. It consists of an RF-370/RK-370 mini motor paired with an Eccentric Vibration Tower Vibration wheel. When powered, the motor’s output shaft drives the eccentric wheel, generating powerful vibrations.It usually is used in Massagers and personal products. With changing the eccentric wheels ,370 motor can generate difference vibration level.We can custom 370 DC Vibration Motor according to your need.

Key Technical Specifications

• Dimensions:

  • Motor Length: 30.8mm ±0.2mm (0.10 inches).

  • Body Size: 24.4mm Max × 30mm (1 × 1.2 inches, D×H).

  • Vibration Wheel Size:13mm*6mm (0.05 ×0.2 inches, D*W).

  • Screw hole distance:17±0.05mm
  • Shaft Length:Customized as your need

• Thread /Screw Holes Size: M3 for easy mounting.

• End Cover structure can be customzied
• Motor Teriminal Angle:Right angle or other angle can customized
• Operating Voltage:1V-36V

• Rated Voltage: DC 2V -36V customized as your need

• No-load Speed:1000RPM-6000RPM customized as your need
• Direction of Rotation；CCW/CW
• Operating Temperature:-25℃ to +85℃

3V 6V 12V Custom 370 DC Vibrating Motor Dimension / Drawing

⇔ Customized Notice:

The above drawings are for reference only, we have provided more than 20,000 customised micro motor solutions for our customers, please feel free to contact us if you have any requirements, our engineers will provide you with one-to-one motor solutions.

Miniature DC Motor Supplier from China — Direct from Factory, Customizable, Cost-Effective

We are a professional manufacturer specializing in the design and production of miniature electric motors. Our product range includes brushed DC motors, brushless DC motors, gear motors, and stepper motors, with diameters from 5.4mm to 45mm and operating voltages ranging from 1V to 36V.

Every motor we produce is custom-tailored to meet the specific needs of our clients’ end products. Unlike standard resellers, we do not keep off-the-shelf stock for small-batch sales (defined as order quantities below 500 units, except for stepper motors). Our focus is on delivering tailor-made motor solutions for businesses seeking higher performance, better integration, and long-term reliability.

Why Choose Us?

Comprehensive Customization Services With over 20 years of experience in motor design and manufacturing, our engineering team responds quickly to customer requirements, offering full-process support from structural design and performance optimization to prototyping. We have delivered over 20,000 customized motor solutions to global clients.	Global Raw Material Sourcing We source high-quality materials worldwide to ensure consistent performance, long lifespan, and cost-efficiency, enabling us to offer more competitive pricing to our clients.	Automated Manufacturing & Quality Assurance Lihua Motor factory features an automation rate of 80%, equipped with advanced production and testing lines that cover key processes including winding, assembly, welding, and performance testing — ensuring consistent quality and fast delivery.
Highly Competitive Pricing Thanks to our large-scale customized production and global procurement strategy, we provide motor solutions with excellent cost-performance ratios, helping clients reduce product costs and gain a competitive edge.		International Certifications & Reliable Quality Our products are certified by CE, ROHS, REACH, ISO 9001, IATF 16949, UL, and more. They are widely used in consumer electronics, smart home devices, small robotics, beauty and medical devices, and automotive applications.

Application Scenarios for Micro DC Motors

Experience compact and efficient motion solutions with our micro DC motors, widely used across key industries to enable precision, reliability, and intelligent automation.

Robotics and Automation
Ideal for precise motion control in:

• Robotic arms and joint drives

• AGV (Automated Guided Vehicle) and AMR wheels

Smart Home Devices
Providing smooth and quiet performance in:

• Automatic curtains and smart locks

• Coffee machines and kitchen appliances

Medical and Healthcare Equipment
Built for safety and accuracy in:

• Infusion pumps and ventilators

• Rehabilitation devices and mobility tools

Industrial Automation
Driving efficiency and control in:

• Conveyor systems and valve actuators

• Packaging and assembly line equipment

IoT and Smart Devices
Compact motors for responsive functions in:

• Sensor actuators and smart mechanisms

• Camera gimbals and tracking systems

Office and Commercial Technology
Reliable operation for:

• Printers, scanners, and vending machines

Mobility Solutions
Powering modern transport and stabilization in:

• Electric carts and mobility aids

• Drone gimbals and lightweight vehicles

Precision Instruments
Supporting fine control and high accuracy in:

• Laboratory equipment

• 3D printers and precision tools

Our micro DC motors are engineered for high performance in compact designs—perfect for today's demands in automation, healthcare, smart living, and more.

3V 6V 12V Custom 370 DC Vibrating Motor Sector shaped Micro miniature Vibration Motor Images
